SPECIFICATIONS

Application: lab

Brand Name: Qudao

Chemical Composition: sio2

Dimensions: customized

Item Name: Standard Quartz Fluorometer Cuvettes Price with Stopper

MOQ: 1PCS

Material: quartz glass

Model Number: QD-quartz cuvette

OEM: Accept Customized

Optical Distance: 10mm

Package: Safe Exported Cartons

Place of Origin: Jiangsu, China

Processing: Deep processing avaliable

Shape: customized

Size: customized size

Usage: Luminosity meter

Volume: 3.5ml

Product Description

Corrosion Resistance 4 sides clear UV Quartz Cuvettes Quartz Flow cell cuvette

1.we supply all kinds optical quartz cuvette: like UV quartz cuvette, standard cuvette with lid, standard cuvette with stopper, micro cuvette, fluorescence cuvette, special requirement cuvettes and so on.

Size, capacity and shape can be customized according your drawing. 2.Optical clear quartz cuvette is acid and alkali resistance 3.Optical clear quartz cuvette with lid is organic solvent resistance 4.Optical Quartz cuvette with lid is sample zero interference

Standard cell with lid specification.

If you need other specification,please send us drawing.

Outside diameter H*W*D (mm)

Path Length  (mm)

Inside Width (mm)

Volume (ml)

55*45*12.5*12.5mm

10

10

3.5

Quartz Glass Cuvette

The cuvette is also called the absorption cell, the sample cell.

Used to hold the reference solution, sample solution. Compatible with spectroscopic instruments such as spectrophotometers,bloodline analyzers,particle size analyzer, etc. quantitative and qualitative analysis of substances, widely used in chemical, metallurgical, medical, pharmaceutical, food, environmental protection, power plants, water plants, oil and other industries, departments and universities, research institutes, testing, testing and use. It is mainly a quartz cuvette fired from quartz powder, and also has a trace amount of Semi-micro, fluorescent and other cuvettes appear.

Our Service:

1. OEM service 2, produce per customers' request such as design & package & printing logo 3, special package for fragile products to make sure no broken in transportation

Product Paramenters

Property Content	Property Values
SiO2	99.99%
Density	2.2×103 kg/cm³
Hardness	5.5 - 6.5 Mohs' Scale 570 KHN 100
Tensile Strength	4.8x107 Pa (N/mm2) (7000 psi)
Compression Strength	>1.1×109 Pa (160,000 psi)
Coefficient of Thermal Expansion	5.5x10-7 cm/cm·°C (20°C-320°C)
Thermal Conductivity	1.4 W/m·°C
Specific Heat	670 J/kg·°C
Softening Point	1730°C (3146°F)
Annealing Point	1180°C (2156°F)
Strain Point	1075°C (1967°F)
Electrical Resistivity	7x107 ohm cm (350°C)

Company Profile

Lianyungang Qudao Quartz Products CO.,Ltd is a quartz glass products’ deep processing enterprise integrating R&D, production and sales . We have a number of cold processing and hot processing production lines for quartz glass products, and hot processing customized products are our unique advantage. Combing with our Continuous innovation in production technology, advanced production and testing Facilities &Equipment,fine workmanship and quality guarantee system , we can help you solve any problems you encounter when using quartz glass products.

Exhibition

Certifications

Packing & Delivery

Meeting all your requirements

Packaging: 1. Inner: 1piece / Bubble paper. Plastic air cushion film. Foam material 2. Outer: Shipping Carton Wooden case/ According to customers' requirement.
Delivery:

1. By Air (China Post Air Mail, ePacket, DHL, UPS, TNT, FEDEX) 2. By Sea (FOB Qingdao,Shanghai etc.)

3. Both air and sea shipment is available, it's depend on your request.
